Hydraulic Rotary Head Specification

Hydraulic Rotary
Drilling Head

The BRUCE Hydraulic Rotary Drilling Head & Augers are designed with a wide range torque, speed and accessories providing for practically CFA auger drilling of high speed, DTH (Down The Hole Hammer) of low speed and Casing drilling

The BRUCE Hydraulic Rotary Drilling Head & Augers Are Designed With A Wide Range Torque, Speed And Accessories Providing For Practically CFA Auger Drilling Of High Speed, DTH (Down The Hole Hammer) Of Low Speed And Casing Drilling

Maximize overall efficiency can be achieved by adapting the highly effective and big size of hydraulic motor. Saving the fuel consumption cost 10%~30%, compared to equivalent Electrical Auger.
Highly reliable gear and durable hydraulic motor

Optionally BRUCE Hydraulic Rotary Heads Are Also Available In An Automatic Torque Control System. Optionally An Appropriate Shock-Sub Is Recommended For DTH Hammer Application

Rotary Head

Hydraulic Single Auger Hydraulic Doughnut Auger Hydraulic Detachable Casing Auger

BRUCE SCA-500 (14,500 kg.m)

Rotation Speed	0~8 rpm
Torque	14,500 kg.m
Hole	640 mm
Casing Size	406~508 mm
Oil Flow	200 lpm
Operating Pressure	300 bar

BRUCE SCA-600 (17,500 kg.m)

Rotation Speed	0~8 rpm
Torque	17,500 kg.m
Hole	640 mm
Casing Size	406~609 mm
Oil Flow	280 lpm
Operating Pressure	300 bar

BRUCE SCA-800 (32,000 kg.m)

Rotation Speed	0~8 rpm
Torque	32000 kg.m
Hole	950 mm
Casing Size	609~912 mm
Oil Flow	350 lpm
Operating Pressure	300 bar

BRUCE SCA-1000 (60,000 kg.m)

Rotation Speed	0~8 rpm
Torque	60000 kg.m
Hole	1050 mm
Casing Size	609~1016 mm
Oil Flow	350 lpm
Operating Pressure	300 bar

BRUCE SCA-8000 (80,000 kg.m)

Rotation Speed	0~8 rpm
Torque	80000 kg.m
Hole	1250 mm
Casing Size	712~1219 mm
Oil Flow	350 lpm
Operating Pressure	300 bar
